Premium Microwave Touchless Sensor IR Switch

Featuring non-touch microwave motion detection technology the ClearWave door activation switch has been designed for installations where hygiene is of paramount importance such as white room, food processing and chemical industry applications

Features:

  • Wireless design, installation free wiring, more flexible installation.
  • Anti-drop screw fixing design.
  • The receiver has a wide voltage input design, and 12-30V AC and DC power input are effective.

Technical data:

  • Surface Installation
  • Material: Plastic
  • Contact rating: 3A, AC 120V / DC 30V
  • Input voltage: DC 12V-24V
  • Output Contact:NO/NC/COM
  • Working temperature(approx.): 0 to 50 ℃
  • Response range: Within 10cm
  • LED indication: Standby: Red LED on, visitors approaching: Green LED on
  • Size:86x55x20mm  and 68x55x20mm

Prices:

SKU Code Product name Price, AUD
PCIRR 001 Premium Contactless IR door Release 86x86x20 75.00
PCIRR 002 Premium Contactless IR door Release 86x55x20 75.00

*Please contact us for more information.

Buy on eBay





Description

Premium Microwave Touchless Sensor IR Switch

Featuring non-touch microwave motion detection technology the ClearWave door activation switch has been designed for installations where hygiene is of paramount importance such as white room, food processing and chemical industry applications

Features:

  • Wireless design, installation free wiring, more flexible installation.
  • Anti-drop screw fixing design.
  • The receiver has a wide voltage input design, and 12-30V AC and DC power input are effective.

Technical data:

  • Surface Installation
  • Material: Plastic
  • Contact rating: 3A, AC 120V / DC 30V
  • Input voltage: DC 12V-24V
  • Output Contact:NO/NC/COM
  • Working temperature(approx.): 0 to 50 ℃
  • Response range: Within 10cm
  • LED indication: Standby: Red LED on, visitors approaching: Green LED on
  • Size:86x55x20mm  and 86x55x20mm



Additional information

Weight 0.2 kg
Dimensions 20 × 50 × 50 mm
